Most casual crypto miners use a conventional motherboard, especially if they have a PC/case/power supply with sufficient PCIe slots for their GPUs. But when you get beyond 2-4 GPUs, you either need a rat’s nest of riser extenders, or maybe (just maybe) a dedicated mining motherboard.
I recently got a new-to-me mining motherboard, and found it painful to find some information and resources I needed. I’m aggregating this information in this post, and it will get updated as I get more relevant experience with the ONDA motherboard in question. If you have any info to share, feel free to comment below and I’ll update. (Last update 2021-03-14)
I’ve mined with an Octominer 8-slot motherboard for 3 years now. In addition to an onboard Celeron 3855U and a single DDR3 SODIMM RAM slot (max of 8GB), it has eight PCIe x16 slots, so you don’t need to use the common x1-to-x16 risers. It’s complicated in that you have to power the motherboard with a number of additional power connectors (in this case, 6-pin PCIe power leads from the power supply). But it sits flat on a custom frame I ordered in 2018, and it doesn’t have much that I don’t need (like lots of drive controllers, extra memory slots, audio, etc). And if you get a custom mining power supply (or breakout board) with only 6-pin connectors, you’re in good shape.
Octominer has discontinued their 8-slot boards, and the boards may not support the latest GPUs on the market (much like the Ethos mining distro I used on it until this past week). I couldn’t get the board to boot with an AMD 5500XT GPU (Amazon, eBay) in the first slot, for example. So it’s chugging along with eight Sapphire Nitro+ RX580 8GB cards (Amazon, eBay), seven of which have been chugging for almost three years now.
While they still make custom boards, the only ways to get their products are either to find the rare used item on a marketplace, or to buy the one integrated rig they currently sell in quantities less than 10 (their x12 rig with everything but the GPUs, which runs almost $1,000 shipped to the US).
Another company making custom boards is ONDA. You can usually find them on eBay or other marketplaces for a couple hundred dollars, with a range of slot support. I found a good deal on the B250 D8P-D4 recently, and since I wanted to aggregate a mess of old GPUs, it was an easy way to go. Continue reading
